White Push Button Membrane Switch , Scissor Switch Membrane Keyboard

White Push Button Membrane Switch , Scissor Switch Membrane Keyboard

  • White Push Button Membrane Switch , Scissor Switch Membrane Keyboard
White Push Button Membrane Switch , Scissor Switch Membrane Keyboard
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Zhongshan Membrane Switch
Certification: RoHS,ISO9001:2000
Model Number: Push Button Membrane Switch
Payment & Shipping Terms:
Minimum Order Quantity: 100pieces
Price: negotiation
Packaging Details: Seal plastic bags with carton boxes or due to customer requirement
Delivery Time: within 7 days after payment
Payment Terms: 30% deposit, 70% balance after shipment
Supply Ability: 50000pieces per week
Contact Now
Detailed Product Description
Keywords: Push Button Membrane Switch Keypad Button: PET/PC/PMMA/PVC
Surface Finish: Glossy Or Matte Operating Power: ≤1W
Rated Voltage: ≤50V DC Working Current: ≤ 100mA
High Light:

push button membrane switch

,

key membrane switch

White Push Button Membrane Switch , Scissor Switch Membrane Keyboard





Push Button Membrane Switch Basic Properties





Electrical Properties:
Rated Voltage



≤50V DC





Rated Current



≤ 100mA



Operating Power



≤1W



Insulation Resistance



≥100MΩ (250V DC)



Loop Resistance



10Ω~2kΩ (based on the design)



Contact Resistance



0.5 ~ 5Ω



Wire Lead Resistance



<1Ω/cm



Base Material Voltage Withstand



1500V DC



Mechanical Properties:





Life Expectancy



Flat type ≥ 5 million times, Tactile type ≥ 1 million times



Operation Force



Flat Type 57-284g ,Tactile Type 170-397g



Dome Rebound Time



≤6ms



Tail Bending Performance



≤180°



Switch Stroke



Flat 0.1~0.5mm,Tactile 0.6~1.5mm



Vibration



20G's max.



Thickness



0.7~1.5 mm



Environmental Properties:





Operation Temperature



-40°C to +80°C (-40°to 176°F)



Storage Temperature



-40°C to +85°C (-40°to 185°F)



Atmospheric Pressure



86 ~ 106 kPa



Humidity



+40°C, 90%~95%RH for 240 Hours
