Square Shape Metal Dome Membrane Switch With PET Double - Sided Tape

Square Shape Metal Dome Membrane Switch With PET Double - Sided Tape

  • Square Shape Metal Dome Membrane Switch With PET Double - Sided Tape
Square Shape Metal Dome Membrane Switch With PET Double - Sided Tape
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Zhongshan Membrane Switch
Certification: RoHS,ISO9001:2000
Model Number: Metal Dome Membrane Switch
Payment & Shipping Terms:
Minimum Order Quantity: 100pieces
Price: negotiation
Packaging Details: Paper carton( outer) and plastic bubble bag (inner).Or per your needs.Special requirement accepted.
Delivery Time: within 7 days after payment
Payment Terms: 30% deposit the 70% balance after shipment, or full payment after air transpotation
Supply Ability: 50000pieces per week
Contact Now
Detailed Product Description
Craft: Screen Printing Max Voltage: 35V
Connector Width: 2.54mm Feature: Water Proof
Material: PET / PC Color: Red Black White Yellow Blue
High Light:

key membrane switch

,

custom membrane switches

Square Shape Metal Dome Membrane Switch With PET Double - Sided Tape





Metal Dome Membrane Switch​ Specification




op Adhesive PET Double-sided Tape   0.10/.125mm
Paper Double-sided Tape   0.10mm
Transfer Tape   0.06/.12mm
Retainer PET Glossy 0.125mm
Spacer PET Double-sided Tape   0.225/.275mm
Circuit Layer PET Glossy 0.125mm
Rear Adhesive Paper Double-sided Tape   0.10mm
  Transfer Tape   0.06/.12mm
Connector Pin   2.54mm Metal,Male/Female
Housing   Female,2.54mm
Conductive Layer Silver Paste   Acheson ELECTRODA 820B
Carbon Paste   Acheson ELECTRODA 423SS
Insulation Ink   Acheson ELECTRODA 452SS


Electrical Performances





Wire Resistance



0.5mm width,<1Ω/cm Rated Current 25-100mA,0-30V DC



Insulation Resistance



>100MΩ 250V DC Working Voltage <50V DC



Non-tactile Switch



0.1-0.4mm Tactile Switch 0.4-1.0mm



Working Life



Working Life Working Temperature -40℃ ~ 70℃



Working Humidity



40℃,98%RH No influence Substrate Voltage 1500V DC



Feedback Time



10ms Tail Folding R>1,180



Metal Dome Membrane Switch​ Advantage



Metal Dome Membrane Switch has the advantage of the whole flat, thin shape, quality, small,



dust-proof, good, good water resistance, is a semi-enclosed structure. In addition, the panel



design, and great freedom of choice of colors. Positive range of applications of desktop



computers, copiers, fax machines, toys, square computer, word processor and other areas of



expansion.



Packaging & Delivery





packaging details: inside,shockproof package, PE bag



outside,thickened carton, water-proof



delivery details: express,2-4 working days



air freight,5-7 working days



sea freight,25 working days
