Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches

Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches

    • Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches
    • Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches
    • Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches
  • Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches

    Product Details:

    Place of Origin: Jiangsu(China mainland)
    Brand Name: Zhongshan
    Certification: ROHSISO9001,2000
    Model Number: ZS-78

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 pieces
    Price: negotiation
    Packaging Details: Seal plastic bags with carton boxes or due to customer detail requirements
    Delivery Time: within one week after receiving order payments
    Payment Terms: 30% deposit, the 70% balance after shipment, or full payment before air transportation
    Supply Ability: 50000 pieces per week
    Contact Now
    Detailed Product Description
    Feature: Water-proof Keypad Button: PET/PC/PMMA
    Material:: PET/PC/PMMA/PCB Product Name: Tactile PCB Membrane Switch
    Printing:: Screen Printing Size:: Customized Size
    High Light:

    pcb membrane keypad

    ,

    pcb tactile switch

    Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches





    Home Appliance Equipment Button With Windows ,Metal Dome switch





    1, operating voltage:



    ≤ 35VDC



    2, working current:



    ≤ 100mA



    3, Contact resistance:



    0.5 ~ 5Ω



    4, Insulation resistance:



    ≥ 100MΩ (100VDC)



    5.Spring Time



    ≤ 6ms



    6.Switch Stroke



    Flat 0.1~0.5mm
    Tactile 0.6~1.5mm
    7.Operation Force Flat 57g~286g
    Tactile 170g~398g



    8.Operation Temperature



    -20℃~ +80 ℃



    9.Storage Temperature



    -40 ℃ ~ +85 ℃ temperature of 95% ± 5%



    10, atmospheric pressure:



    86 ~ 106kDa



    11.Life expectancy



    Flat 500Million-1000Million
    Tactle 100mi



    Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches 0Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches 1



    Packaging & Delivery


    Packaging Details



    PCB Membrane Switch


    first put 50pcs into poly bag, then packed into big carton, carton size according to customer's



    requirement



    Delivery Time  10-12days





    PCB Membrane Switch,1*7 Embossed Button With Metal Dome



    Company Introduction



    Over 13 Years in the Membrane Switch Industry,Founded in 2002, Nanjing Zhongshan



    Membrane Switch is a professional membrane switch manufacturer in China. Our professional



    operation can ensure you of quality products supported by mechanical, electronic and control



    automation. Based on our good abilities in technology and production workmanship, our



    products are strictly checked by our quality supervision department. For your added



    assurance, our plants are ISO 9001:2000-certified and our products are compliant with the



    RoHS Directive..



    “Our 3,000sqm factory houses three production lines furnished with advanced equipment to



    manufacture up to 6 million pieces monthly. We are serving customers in Asia, the US,



    Europe, Australia and other areas worldwide.



    Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches 3





    Our Service



    1. OEM Order welcome: Product, Package...


    2. Sample order Before mass production


    3. We will reply you for your inquiry in 24 hours.


    4.After send sample, we will supply tracking number,when you got sample, test sample, if



       sample have problem , please contact with us, we will solve problem at the first time,
