Detailed Product Description
Material: Pet Color: Blue, Black Red Green
Current Contact: 2-24V Thickness: 0.3mm
Diemension: 115*130mm Surface: Flat And Tactile
High Light:

sealed membrane keypad

,

flat membrane switch

America designed item / ZS-31 / 175mm*175mm / Metal Dome Tactile



Membrane Switch with Pins and Sheilding Layer

What Is A Membrane Switch?





Membrane switches are generally made from five different layers. This includes membrane,



graphic, tactile, rigid and static layers. The first layer contains the graphic interface for the



user to control the machine. It can also include a flexible circuit for less expensive



alternatives.



Another layer will contain the printed circuit which allows a signal to be transmitted. The ink



that is used for the printing on the circuit is generally made up of a variety of metals. This



helps for the signal to be conductive for turning on and off.



Membrane switches allow forcommunication to take place in electronic devices. Membrane



switches are a piece of equipment that can be highly sophisticated or rather simple by design.



Embossed Tactile Colorized Sealed Membrane Switches With Shielding Circiuit 0

Embossed Tactile Colorized Sealed Membrane Switches With Shielding Circiuit 1Embossed Tactile Colorized Sealed Membrane Switches With Shielding Circiuit 2

Features:



1. Material: PET/PC with different thickness and finish


2. Button effect: embossing + metal domes respectively for good tactility and perfect



    feedbacks. we can offer the other options: a. embossing, no metal domes.


3. metal domes, no embossing.


4. no embossing, no metal domes (flat type)

5. LCD clear window can be made.


6. Colors for graphics are matched with Pantone No., Bi-color leds are also available.



Electrical Performances



Wire Resistance



0.5mm width,<1Ω/cm Rated Current 25-100mA,0-30V DC



Insulation Resistance



>100MΩ 250V DC Working Voltage <50V DC



Non-tactile Switch



0.1-0.4mm Tactile Switch 0.4-1.0mm



Working Life



Working Life Working Temperature -40℃ ~ 70℃



Working Humidity





40℃,98%RH No influence Substrate Voltage 1500V DC



Feedback Time



10ms Tail Folding R>1,180
