Name: Screen Printing PCB Tactile Switch / Waterproof Single Button Membrane Switch
Brand: Nanjing Zhongshan Membrane Switch Co., Ltd.
SKU: ZS-78
Price: 2.50 USD
Availability: InStock

Home > products > PCB Membrane Switch >

Screen Printing PCB Tactile Switch / Waterproof Single Button Membrane Switch

pcb membrane keypad

pcb tactile switch

Place of Origin:

Jiangsu(China mainland)

Brand Name:

Zhongshan

Certification:

ROHSISO9001,2000

Model Number:

ZS-78

Request A Quote

Product Details

Name:

PCB Tactile Switch

Keypad Button:

PET/PC/PMMA

Material::

PET/PC/PMMA/PCB

Product Name:

Single Button Membrane Switch

Printing::

Screen Printing

Size::

Customized Size

Highlight:

pcb membrane keypad

pcb tactile switch

Payment & Shipping Terms

Minimum Order Quantity

100 pieces

Price

negotiation

Packaging Details

Seal plastic bags with carton boxes or due to customer detail requirements

Delivery Time

within one week after receiving order payments

Payment Terms

30% deposit, the 70% balance after shipment, or full payment before air transportation

Supply Ability

50000 pieces per week

Metal Dome Embossed PCB Membrane Switch Keypad 0.3mm

Get Best Price

Professional Embossed Tactile PCB Membrane Switch Panel China With LED Window

Get Best Price

Waterproof Tactile PCB Membrane Switch , Customized Size Sealed Membrane Switches

Get Best Price

Embossed Tactile Electronic PCB Membrane Switch Keyboard With 3M 467 Adhesive

Get Best Price

Contact Now

Product Description

Screen Printing PCB Tactile Switch / Waterproof Single Button Membrane Switch

Single Button Membrane Switch Application

Home Appliance Equipment Button With Windows ,Metal Dome switch

1, operating voltage:	≤ 35VDC
2, working current:	≤ 100mA
3, Contact resistance:	0.5 ~ 5Ω
4, Insulation resistance:	≥ 100MΩ (100VDC)
5.Spring Time	≤ 6ms
6.Switch Stroke	Flat 0.1~0.5mm
6.Switch Stroke	Tactile 0.6~1.5mm
7.Operation Force	Flat 57g~286g
7.Operation Force	Tactile 170g~398g
8.Operation Temperature	-20℃~ +80 ℃
9.Storage Temperature	-40 ℃ ~ +85 ℃ temperature of 95% ± 5%
10, atmospheric pressure:	86 ~ 106kDa
11.Life expectancy	Flat 500Million-1000Million
11.Life expectancy	Tactle 100mi

Packaging & Delivery

Packaging Details

PCB Membrane Switch
first put 50pcs into poly bag, then packed into big carton, carton size according to customer's

requirement

Delivery Time 10-12days

Company Introduction

Over 13 Years in the Membrane Switch Industry,Founded in 2002, Nanjing Zhongshan

Membrane Switch is a professional membrane switch manufacturer in China. Our professional

operation can ensure you of quality products supported by mechanical, electronic and control

automation. Based on our good abilities in technology and production workmanship, our

products are strictly checked by our quality supervision department. For your added

assurance, our plants are ISO 9001:2000-certified and our products are compliant with the

RoHS Directive..

“Our 3,000sqm factory houses three production lines furnished with advanced equipment to

manufacture up to 6 million pieces monthly. We are serving customers in Asia, the US,

Europe, Australia and other areas worldwide.

Our Service

1. OEM Order welcome: Product, Package...
2. Sample order Before mass production
3. We will reply you for your inquiry in 24 hours.
4.After send sample, we will supply tracking number,when you got sample, test sample, if

sample have problem , please contact with us, we will solve problem at the first time,
