Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface

Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface

    • Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface
    • Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface
    • Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface
  • Embossed Metal Dome FPC Membrane Switch With Protective Film On Surface

    Product Details:

    Place of Origin: Jiangsu (China mainland)
    Brand Name: Zhongshan
    Certification: ROHS ISO9001,2000
    Model Number: ZS-66

    Payment & Shipping Terms:

    Minimum Order Quantity: 500pieces
    Price: negotiation
    Packaging Details: Seal plastic bags with carton boxes or due to customer detail requirements
    Delivery Time: within one week after receiving payment
    Payment Terms: 30% deposit, the 70% balance after shipment or full payment after air transportation
    Supply Ability: 50000 pieces per week
    Contact Now
    Detailed Product Description
    Material: Pet Current Contact: 2-24V
    Suface: Matte Thickness: 0.3mm
    Color: Black Red White Brand Name: Zhongshan

    With a clear window and embossed metal dome Membrane Switch / ZS-



    66 / with a protective film on the surface



    Product Description:



    1, Membrane switch ( Tactile membrane switch and Non-tactile membrane switch)



    2, Silicon rubber keypad and keyboard.



    3, Graphic overlay



    4, PCB / PCB+assembly / FPC / flex PCB



    5, Touch screen



    6, Metal touch metal key switch



    7, Backlighting



    8, Thru hole silver flex circuit



    9, Metal dome





    Technical Parameters





    1. Electrical



    Maximum Circuit Rating: 35V(DC),100mA,1W



    Contact Resistance: 10Ω~ 500Ω (Varies from the trace length and material)



    Insulation Resistance: 100MΩ 100V



    Dielectric: 250 Vrms (50~60Hz 1min)



    Contact Bounce: < 5ms



    Life: Flat: ≥ 5million times



    Tactile: ≥ 1 million times



    Duraswitch: ≥ 10million times



    2. Mechanical



    Actuation Force: Flat: 57~284g(2~10oz)



    Tactile: 170~397g(6~14oz)



    Switch Height: Flat: 0.1~0.5mm



    Tactile: 0.6~1.5mm



    Embossed Metal Dome FPC Membrane Switch With Protective Film On SurfaceEmbossed Metal Dome FPC Membrane Switch With Protective Film On Surface

    Nanjing Zhongshan Membrane Switch Co.,LTD is located in Jiangsu Nanjing which near



    Airplane Station or Railway Station with convenient transportation, together with the art



    equipments enables us to meet all of your needs on products.





    Zhongshan specializes in membrane switch, metal keypad and keyboard, PCB and PCBA



    control module, FPC, silicon plastic composite membrane switch ,silicon rubber keypad, touch



    screen etc, experienced with their rapid prototyping, design and application, we are ready to



    help make it easy to put a custom product to market. Zhongshan products are widely used



    in areas like medical, industrial control, military, intelligence control, aviation, fitness, security



    products and intelligent digital products etc.



    Embossed Metal Dome FPC Membrane Switch With Protective Film On SurfaceEmbossed Metal Dome FPC Membrane Switch With Protective Film On Surface





    Our advantage:



    1, Over 16 years experience.



    2, Customized turnkey solutions.



    3, ODM & OEM service.



    4, Short lead time & high quality



    5, NO MOQ.



    6, Quick turn prototype



    7,UL,ISO and ROHS certified factory.





    Quotation Requirement :





    1, Material



    2, Dimension.



    3, Drawings , ( CorelDraw, EPS, AutoCAD Dwg , DXF )



    4, Color



    5, Embossing type : Flat or Emboss



    6, Key type : Flat or Tactile key ( Tactile key : metal dome or poly dome)



    7, Cable : The direction and length



    8, connector tail type



    9, Window : clear or transparent window



    10, Surface : Glossy or matte



    11, Rear adhesive : 3M467,3M468,3M9080 etc……





    Shiping method:





    1) By DHL, Fedex, UPS, TNT etc.



    2) By sea if it is possible



    3) By air
